Arch Size

:

600W x 850H mm (Standard)

Strap Cycle Speed

:

28 Cycles / per Min.

Tension Strength

:

70Kgs / Max.

Strap Width

:

9~15mm

Sealing Method

:

Heat Sealing

Power Supply

:

110/220V 50/60HZ 1PH.

220/380V 50/60HZ 3PH

Dimensions

:

1400L x 640W x 1740H mm

Features:

» With indicating and detecting functions when forward feeding strap positioning.

» The retry feeding of auto correcting function to correct failure strap.

» Safety internal control voltage: 24Volt. (Optional)

» Equipped with 2 photocells and strap switch for 1 or 2 straps.

»All side-sealing models should notice the minimum height of the packaging area

»Side-sealing models can be equipped with minimum 2 photocells to cooperate with existed input and output conveyors with controlling circuitry and the model will add -2HT in the end.
