Design and manufacturing in Taiwan.

Power source: 400V 50Hz 3phase
Design speed: 120 cut/min
Operating speed: 100 cut/min
Cuttinglength:130~220mm
Cutting height: 60-120 mm
Cuttingwidth:100mm
Circle blade: (OD) 610 mm, (ID) 68.26 mm
Transport type: 1 Line conveyor
Power: 3.75kW Gear reducer * 1 unit,
1.8kW Servo motor * 1 unit,
3.75kW motor * 1 unit
Transmission: belt, chain, timing belt
10.Motor: Siemens or TECO
11. Inverter: Yaskawa
12. Electric equipment: CE standard components
13. Provide with CE declaration
14.Control system: touch screen
15.Exclude air compressor

Machine size: (Approx.)
(L) 2000 mm * (W) 2000 mm * (H) 2000 mm
